Description
ELECTRICAL DATA
Rated power 12.50 W
Nominal voltage 220...240 V
Network frequency 50...60 Hz
Rated current 85,000 mA
Inrush current 4.5 A
Power factor λ > 0.5
Protection class I
Operating mode Electronic control device (ECG)
PHOTOMETRIC DATA
Light flux 980 lm
The total luminous flux of the included light sources is 1450 lm
Light output 75 lm/W
Color temperature 3000K
Light color (designation) Warm white
Color rendering index Ra ≥80
Beam angle 110°
DIMENSIONS AND WEIGHT
Length 131.00 mm
Height 110.00 mm
Width 91.00 mm
Product weight 630.00 g
MATERIALS AND COLORS
Product color White
Body material Aluminum
Coating material Polymethyl methacrylate (PMMA)
Mercury content 0.0 mg
USE AND ASSEMBLY
Ambient temperature range -20...+40 °C
Connection type Screw terminal
Type of protection IP44
Protection class IK (impact resistance) IK03
Mounting type Surface
Installation location Wall
With light source Yes
Service life L70/B50 at 25 °C 30000 h
Number of switching cycles 15000
CONTROL DEVICES
ECG - output voltage 36 V
Output current 300 mA
CERTIFICATES AND STANDARDS
Standards CE, EAC, UKCA
