LED headlights

Dimensions: ø 144.00 x 88.00mm
Weight: 1.25 kg (net 1.25 kg)
Voltage: 10-30V
Reference value: 12.5
IP rating: IP66, IP69K
Details: 5 ¾ LED, with standing light,
 7" adapter frame, lens: UV and computer hardened,
 aluminium housing. ø144.4x88mm, 15W: low beam 12V - 1.31A,
 high beam 12V - 1.32A, R112/R87 /R10/R7, IP66/IP6K9K,
 operating temperature -40°C ... +50°C
Warranty (months): 12

Dimensions: ø 85.00 (118.00) x 109.50 mm
Weight: 1.20 kg (net 1.00 kg)
Voltage: 10-30V
Lumens: 2000/5600 lm
Lumens (measured): 800/2400 lm
Reference value: 17.5
Shape: round
Colour temperature: 5000 K
Lens material: polycarbonate
IP rating: IP66, IP6K9K
Approvals: R149, R10, CISPR 5.
Class R510, Class R510, Class R510, Class R510, Class R510, Class R510, Class R510, Class R510, Class R510, Class R510, Class R510, Class R510, Class R510, Class R510, Class R510
Details.

Lamp Type: LED
Number of LEDs: 5
Voltage (DC): 10–32 V DC
Theoretical output (W) 12V 30W low beam 60W high beam
Theoretical output (W) 24V 30W low beam 60W high beam
Power consumption (W) 12V 24W low beam 41W high beam
Power consumption (W) 24V 24W low beam 41W high beam
Functions High beam, low beam, white parking light, amber parking light, indicator
Theoretical lumens 5000 (high beam) 2,000 (low beam)
Actual lumens 2,273 (high beam) 876 (low beam)
1 LUX @ m 275 (high beam) 171 (low beam)
Kelvin 6000
IP rating 67, 68, 69 thousand
Housing color Black
DT6 connector (built-in)
Material of bracket: Cast aluminum
Length (mm) 220
Depth (mm) 80.5
Height (mm) 152
Height, including bracket (mm) 197.2
Operating temperature -30°C to +65°C
E-approved Yes
Complies with Regulation R148, R149
Reference number 17.5
EMC ECE R10

Lamp Type: LED
Number of LEDs: 5
Voltage (DC): 10–32 V DC
Theoretical Output (W) 12V 30W low beam 60W high beam
Theoretical output (W) 24V 30W low beam 60W high beam
Power consumption (W) 12V 24W low beam 41W high beam
Power consumption (W) 24V 24W low beam 41W high beam
Functions High beam, low beam, white parking light, amber parking light, turn signal
Theoretical lumens 5000 (high beam) 2,000 (low beam)
Actual lumens 2,273 (high beam) 876 (low beam)
1 LUX @ m 275 (high beam) 171 (low beam)
Kelvin 6,000
IP rating 67, 68, 69,000
Housing color Black
DT6 connector (built-in)
Material of bracket: Cast aluminum
Length (mm) 220
Depth (mm) 80.5
Height (mm) 152
Height, including bracket (mm) 197.2
Operating temperature -30°C to +65°C
E-approved Yes
Complies with Regulation R148, R149
Reference number 17.5
EMC ECE R10

Package size: 1/12
Dimensions: 157,00 x 93,00 mm
Weight: 4.50 kg (net 4.50 kg)
Voltage: 9-32V
Lumens: 5600 lm
Lumens (measured): 2690 lm
Socket: H4
Reference value: 17.5
Colour temperature: 6000 K
Frame material: aluminium
Lens material: polycarbonate
IP rating: IP68
Approvals: ECE R148, R149, R10, CISPR 25 Class 4
Details: Agriline 3x5, with H4 plug, polycarbonate lens,
 aluminium housing, 5600lm, (tested 2690lm), Low 13.7V/ 1.51A,
 High 13.7V/ 3.89A, 6000K, IP68, Valtra: A-A3, C, M, N-N3, S, T-T3,
 XM
Warranty (months): 12

Description

LED Headlight with Fog Light and Heated Lens L3438

The L3438 LED front P/M headlight with a heated lens makes the truck much more visible, making driving safer regardless of conditions and time of day. The headlight features 51 LEDs that emit a bright light, making the vehicle highly visible and reducing the risk of accidents.

Thanks to its 5 lighting functions—high beam, low beam, turn signals, fog lights, and parking lights—the L3438 LED P/M headlight can be used for a wide range of applications, ensuring safer maneuvers. The headlight has all the necessary approvals, is made of durable materials, and its high IP rating protects it from dust and moisture.

Features of the L3438 LED P/M Headlight with Heated Lens

The headlight improves the truck's visibility on the road

Good vehicle visibility improves safety for all road users

The large number of LEDs makes the truck highly visible

5 lighting functions expand the flashlight's range of uses

The durable construction protects the most important components from damage

A high protection rating protects the lamp from dust and moisture

Technical Specifications for the L3438 LED P/M Headlight with Heated Lens

Power: 17/34/15/11/5 W
Voltage: 12/24 V
Diode type: LED
Number of LEDs: 51
Luminous flux: 1200/2200 lm
Approvals: R10, R148, R149
Protection class: IP67
Cable length: 400 mm
Mounting: screw
Lens material: glass
Housing material: aluminum
Dimensions: 188 × 236.8 × 85.7 mm
Package dimensions: 385 × 370 × 400 mm
Weight: 2.06 kg
Quantity per carton: 6 pcs.

Dimensions: 340x75x85mm Weight: 2.30 kg (net 2.30 kg) Type: Reference 12.5 Voltage: 9–36 V Function: melts snow and prevents ice buildup on the left side—turns off when
the internal temperature reaches +50°C,
low beam—high beam—turn signal – parking,
die-cast aluminum housing: UV-protected and impact-resistant,
tempered glass lens, PC reflector, bracket:
stainless steel, integrated 6-pin Deutsch connector.
Low beam 20W 1800lm (raw) - 1500lm (eff),
High beam 38W 3600lm (raw) - 2900lm (eff), signal 18W, parking light 1.5W, 5500K, current (high beam) 12V–24V 3.51–7. 12.5, IP68, 5–10G, CE, ECE R112, EMC R10, R6, R7, operating temperature -40°C … +60°C Warranty (months): 24

Dimensions: 340x75x85mm
Weight: 2.30 kg (net 2.30 kg)
Type: Reference 12.5
Voltage: 9–36 V
Location: on the right
melts snow and prevents ice buildup—turns off,
 when the internal temperature reaches +50°C,
low beams – high beams – turn signal – parking lights,
die-cast aluminum housing: UV-protected and impact-resistant,
 tempered glass lens, PC reflector, bracket:
 stainless steel, with an integrated 6-pin Deutsch connector.
 Low beam 20W 1800 lm (raw) - 1500 lm (eff),
 High beam 38W 3600lm (raw) – 2900lm (eff), turn signal 18W, parking light 1.5W, 5500K, current (high beam) 12V 24V 3.51–7. 12.5, IP68, 5–10G, CE, ECE R112, EMC R10, R6, R7, operating temperature –40°C … +60°C
Warranty (months): 24

Product Description

The SANVI Bi-LED + Laser Projector Module Kit is a high-performance headlight upgrade that provides much brighter and more precise lighting than standard headlights.

These headlights combine Bi-LED technology (low and high beams) with a laser auxiliary beam, which provides an exceptionally powerful and long-range beam. High-quality projector lenses ensure an even and focused distribution of light on the road, improving visibility at night and in poor weather conditions.

This kit is ideal for upgrading car headlights (retrofit projects) and for professional installation.

Key Features

• 🔦 Bi-LED + laser technology – exceptionally bright light

• 🚗 Low and high beams in a single module

• 💡 High-quality projector lenses for a precise beam of light

• 🌙 Improved night visibility

• ⚡ Energy Efficiency

• 🛠 Suitable for retrofitting car headlights

• ✨ A modern and powerful automotive lighting solution

Technical Information

• Product Type: Bi-LED + Laser Projector Module

• Light color: 6000K white light

• Manufacturer: SANVI

• Certifications: CE, FCC, RoHS

• Country of origin: China

• Application: Car Headlight Upgrades

The set includes

• 2 × SANVI Bi-LED + laser projector modules (left + right)

Description

LED Headlight with Strobe Function and Heated Lens L3439

An upgraded LED headlight designed for trucks and heavy equipment, combining driving, warning, and clearance light functions in a single compact housing. The headlight also features a strobe mode and a heated lens, ensuring full functionality even in challenging weather conditions. The use of different light colors allows for clear indication of the vehicle’s position and direction of travel.

Thanks to its large number of LEDs and aluminum housing, the light offers high durability and powerful illumination, while remaining impact- and moisture-resistant. It can be installed in 12/24 V systems, which expands the light’s range of applications. Simple wiring and a long cable allow for quick integration into a vehicle.

Product Features

High beam, low beam, turn signal, parking light, and strobe modes—full functionality in a single headlight

Heated glass – ensures visibility even in winter

12/24 V power supply – universal compatibility with various vehicles

High resistance to water and dust (IP67) – operation in a variety of conditions

Aluminum housing – efficient heat dissipation and durability

Technical Specifications

Power: 17/34/15/7/5 W
Voltage: 12/24 V
Number of LEDs: 81
Low-beam luminous flux: 1200 lm
High-beam luminous flux: 2,200 lm
Mounting: screw
Approvals: R10, R65, R148, R149
Protection rating: IP67
Lens material: glass
Housing material: aluminum
Package dimensions: 385 × 370 × 400 mm
Weight: 2.04 kg
Quantity per box: 6

Description

LED Headlight with Heated Lens L3437

The L3437 LED headlight with a heated lens makes the truck much more visible, making driving safer regardless of the conditions or time of day. The headlight has 48 LEDs that emit a bright light, making the vehicle highly visible and reducing the risk of accidents.

Thanks to its 4 lighting functions — high beam, low beam, turn signal, and parking light — the L3437 LED headlight can be used for a wide range of applications, ensuring safer maneuvers. The headlight has all the necessary certifications, is made of durable materials, and its high IP rating protects it from dust and moisture.

Features of the L3437 LED Headlight with Heated Lens

The headlight improves the truck's visibility on the road

Good vehicle visibility improves safety for all road users

The large number of LEDs makes the truck highly visible

4 lighting functions expand the flashlight's range of uses

The durable construction protects the most important components from damage

A high protection rating protects the flashlight from dust and moisture

Technical Specifications for the L3437 LED Headlight with Heated Lens

Power: 17/34/15/5 W
Voltage: 12/24 V
Diode type: LED
Number of diodes: 48
Luminous flux: 1200/2200 lm
Approvals: R10, R148, R149
Protection rating: IP67
Cable length: 400 mm
Mounting: screw
Lens material: glass
Housing material: aluminum
Dimensions: 195.1 × 188 × 85.7 mm
Package dimensions: 370 × 315 × 400 mm
Weight: 1.78 kg
Quantity per box: 6 pcs.

Dimensions: 325.00 x 72.00 x 65.00 mm
Weight: 2.50 kg (net 2.50 kg)
Voltage: 6-30V
Lumens: 1800/3600 lm
Lumens (measured): 1170/2340 lm
Location: right
Colour temperature: 5000 K
Plug type: 6-pin DT
Lead length: 500 mm
IP rating: IP68, IP69K
Approvals: ECE R148, R149, R10, R65
Model name: AURA
Information: LED headlamp, right, Lo 1800lm - Hi 3600lm, parking, turn indicator, warning light, automatic glass heating when warning light or parking light comes on.Low: 2.0/1.0A @12/24V. High: 3.9/1.9A @ 12/24V.


Warranty (months): 36

The Optibeam Aura has been developed with a modern design that blends perfectly with the vehicle's appearance and emphasises its elegance. The optimum lamp size makes it compatible with most vehicles, combining functionality and aesthetics. Optibeam Aura's 3600 lumens and 5000 Kelvin colour temperature provide bright and natural lighting in all conditions. Thanks to its versatile functions, the Aura offers driving lights, dipped beams, parking lights and warning lights. This makes it the perfect choice for all driving and weather conditions, improving both visibility and safety. One of the most important features of the Aura is the glass heating system, which prevents frost and ice from forming on the lens. This guarantees excellent performance in cold and challenging weather conditions, allowing you to concentrate on driving without worrying about the functionality of the headlights. The versatile features of the Optibeam Aura make it a true all-in-one solution. Its dipped and main beam, parking light and warning light offer unique adaptability to different driving and working situations.

Dimensions: 325.00 x 72.00 x 65.00mm
WeightWeight : 2.50kg (net 2.50kg)
Voltage: 6-30V
Lumens1800/3600 lm
Lumens (measured): 1170/2340 lm
Location: Left
Colour temperature: 5000 K
Plug type: 6-pin DT
Wire length: 500 mm
IP rating: IP68, IP69K
Approvals: ECE R148, R149, R10, R65
Model name: AURA
Information: LED headlight, left, Lo 1800lm - Hi 3600lm, parking, turn signal, warning light, automatic glass heating,
current consumption: Low: 2.0/1.0A @12/24V. High: 3.9/1.9A @ 12/24V.

Warranty (months): 36

Lamp Type: LED
Number of LEDs
High Beams: 4 Low Beams: 2 Parking Lights: 2 Indicators: 8
Voltage (DC) 10-30V DC
Theoretical Efficiency (W) 12V
High beam: 38W Low beam: 20W Parking light: 1.5W Indicator: 20W Heated lens: 20W
Theoretical power (W) 24V
High beams: 38W Low beams: 20W Parking light: 1.5W Turn signal: 20W Heated lens:20W
Features
High beam Low beam Parking light Indicator Heated function
Theoretical lumens High beam: 3600LM Low beam: 1,800 LM Parking light: 220 LM Indicator: 560 LM
Actual lumens High beam: 2,900 LM Low beam: 1,500 LM Parking light: 130 LM Indicator: 420 LM
1 LUX @ m High beam: 280 Low beam: 163
Kelvin 5500
IP Rating 68
Housing Color Black
Lens Color Clear
Beam Pattern High Beam
Position Light Yes
Connection DT
Cable Length (mm) 300
Bracket material Stainless steel
Housing/chassis material Aluminum
Lens material Tempered glass
Length (mm) 229
Depth (mm) 80
Height (mm) 150
Height, including bracket (mm) 170
Operating temperature -40~+60 °C
ADR-approved No
E-approved Yes
Complies with ECE Regulations R112, R7, R6
Reference number 17.5
EMC ECE R1
Description: Headlight with functions: high beam, low beam, parking light, and turn signals. The headlight has E-approval with reference number 17.5 and is equipped with a heated lens. The purpose of the heated lens is to prevent snow and ice from forming on the lamp. The turn signals can be switched between the right and left sides.

Dimensions: 233x193x110mm
Weight: 2,60 kg
Voltage: 9-32V
Location: right
Info: Sculptor N6002 Dualbeam,
 Right, Low beam (22W), High beam (44W),
 Turning beam (17.5W), Parking beam (2.7W),
 Integrated Deutsch-plug 6-pin. IP68, IP6K9K, ECE R112,
 EMC CISPR 25 Class 3, R6, R7
