LED driving beam

OPTIBEAM Savage 9
The Optibeam Savage series - ruthlessly powerful auxiliary lights. Thanks to the excellent optical design, the Savage's almost frightening light output remains within the desired range. The revolutionary Streetshine Ambient parking solution gives Savages a whole new kind of bold, eye-catching look. The colour of the position light can be chosen between orange and white. This function can be easily controlled with a separate cable. The Streetshine Ambient Position Light solution is unique and together with the top level High Beam solution Savage sets a completely new standard for supplementary lighting. The versatile innovative series of auxiliary lights is suitable for both professional heavy traffic and normal car use.

Details: 8 x Osram, white and amber marker lights, complete with chrome frame, 1lux @431m, 4.55A @13.7V

Lamp type LED
PCS LEDs 18
Voltage (V DC) 10-32V DC
Theoretical Effect (w) 12V 126
Theoretical Effect (w) 24V 126
Consumption (w) 12V 104
Consumption (w) 24V 105
Theoretical lumen 12600
Actual lumen 10700
1 LUX @ m 644
Kelvin 6500 th
IP class 67/69 th
Connection
DT-4
Cable length (mm) 1000
Length (mm) 216
Depth (mm) 76
Height (mm) 199
Height, including bracket (mm) 213,7
Operating temperature -35 - +60°C
ADR approved No
E-approved No
EMC ECE R10

New for the season, a fierce addition to the range of round, powerful auxiliary lights. Attracts attention with its appearance, features and performance! Futuristic design, in dark tones, equipped with two parka color options and light output, which is undeniably a wedge in the top fight. Highest polished optics: optimal light distribution. A warning light is built into the top of the lens.

Information: 16 LEDs, two parking light color options: amber and bright, integrated warning light neatly hidden in the upper part of the lens. The frameless lens is shock and impact resistant and won't collect dirt or snow. The mounting leg is designed so that the installation of adjacent lamps goes smoothly. Mode button on the back to switch between off road mode and R149 E approved mode. Current consumption 11.86A @ 13.7V DC.

Lamp type LED

PCS LEDs 28
Voltage (V DC) 10-48V DC
Theoretical Effect (w) 12V 145
Theoretical Effect (w) 24V 141
Consumption (w) 12V 146
Consumption (w) 24V 142
Theoretical Lumen 16800
Actual Lumen 12076
1 LUX @ m 450
Kelvin 6000
IP class IP67
Colour case Black
Connection DT4 (built-in)
Cable length (mm) 1000
Material bracket Stainless steel
Length (mm) 220
Depth (mm) 85
Height (mm) 220
Height, including bracket (mm) 239
Diameter (mm) 220
Operating temperature -40 - +65°C
ADR approved
No
E-approved
Yes
As per regulation
ECE R148, R149
Reference number
50
EMC
ECE R10

Lamp type LED
Voltage (V DC) 10-48V DC
Theoretical effect (w) 12V 145
Theoretical effect (w) 24V 141
Consumption (w) 12V 145
Consumption (w) 24V 142
Features
Luminous Lumens, warning light
Theoretical lumen 16800
Actual lumen 12076
1 LUX @ m 450
Kelvin 6000
IP class IP67
Colour body Black
Colour lens Clear
Colour LEDs Amber and white
Position light Yes
Connection DT6
Cable length (mm) 150
Material bracket Stainless steel
Length (mm) 220
Depth (mm) 220
Height (mm) 85
Height, including bracket (mm) 239
Diameter (mm) 220
Operating temperature -40 - +65°C
ADR Approved No
E-approved Yes
Complies with Regulation R10, R65(XA2), R149, R148
Reference Number 50
EMC Yes

Light Type: LED
Number of LEDs: 34
Voltage (DC) 9–35 V DC
Theoretical output (W) 12 V 170
Theoretical output (W) 24 V 170
Power consumption (W) 12 V 144.7
Power consumption (W) 24V 143.5
Theoretical lumens 14,280
Actual lumens 10,485
1 LUX @ m 900
Kelvin 6,000
IP rating 67/69
Housing color Black
Lens color Clear
LED colors White and amber
Position light White and amber
Connection DT-4
Cable length (mm) 500
Bracket material Stainless steel
Housing/chassis material Aluminum
Lens material Polycarbonate
Length (mm) 228.6
Depth (mm) 86.7
Height (mm) 228.6
Height, including bracket (mm) 249.3
Diameter (mm) 228.6
Operating temperature -30°C to +65°C
E-Approved No
EMC ECE R10

A combination of two beam patterns—the Siberia NR Spot and Siberia NR—is the ideal solution for optimal forward visibility, providing a balanced field of view in both length and width. Installation examples: 2 Siberia NR Spot units provide 1 LUX at a distance of 1,300 meters. 2 Siberia NR Combo units + 1 Spot unit in between provide 1 LUX at a distance of 1,100 meters.

Amber or white? Which color best reflects your style and personality? The two-tone light lets you choose. Regardless of your choice—the position light provides an outstanding lighting effect, perfectly positioned in a circle with a break line in the middle.

The lens is made of transparent PC (polycarbonate), an exceptionally durable material with good light transmission that protects the LEDs from scratches and weather conditions. The durable black aluminum housing withstands salt and other stresses caused by the harsh Nordic climate.

Lamp Type: LED
Number of LEDs: High beams: 8 (4 x 10W + 4 x 20W); Parking lights: 4 x 0.5W; Warning lights: 2 x 3W
Voltage (V DC) 9–36 V DC
Theoretical output (W) 12 V 120
Theoretical output (W) 24 V 120
Power consumption (W) 12V 112
Power consumption (W) 24V 98
Functions: High beam, parking light, warning light
Theoretical lumens 12,000
Actual lumens 10,500
1 LUX @ m 439
Kelvin 6,000
IP rating 68/69
Housing Color Black
Lens Color Clear
LED Color White/Amber
Position Light Yes
Connection Cable
Cable Length (mm) 2500
Bracket material Stainless steel
Housing/chassis material Aluminum
Lens material Polycarbonate
Length (mm) 247
Depth (mm) 70.7
Height (mm) 141
Height, including bracket (mm) 170.5
Operating temperature -40 to +60°C
ADR-approved No
E-approved Yes
Complies with Regulation
ECE R112, R7, R65

Reference Number 45
, EMC, ECE R10

ONE LIGHT – THREE FUNCTIONS
The Dark Knight Insane provides all the lighting you need in a single light: a running light with a warning light and a two-tier clearance light—choose between amber or white.

HIGH PERFORMANCE
The Dark Knight Insane is designed to be visible from all angles on the road. Its beam pattern requires a perfect balance of length and width. The technology enhances overall efficiency by collecting and directing light in perfect balance, right where it’s needed. Dark Knight Insane is ideal for both day and night. Experience the fearless eyes of the knight from a unique lighting perspective. Watch and enjoy the soft-start effect, in which the light intensity slowly increases before finally reaching its full power.

DARK KNIGHT DESIGN
The dark details and sleek design make it easy to install.

Optibeam Savage series - ruthlessly powerful auxiliary lights. Thanks to the excellent optical design, the Savage's almost frightening light output stays within the desired range. The revolutionary Streetshine Ambient parking solution gives Savages a whole new kind of bold, eye-catching look. The Streetshine Ambient light solution is unique and together with the top-of-the-range driving light solution, Savage sets a whole new standard for supplementary lighting. The versatile innovative series of auxiliary lights is suitable for both professional heavy traffic and normal car use.

Dimensions: ø 170,00 x 94,00mm
Voltage: 10-32V
Lumen: 3000 lm
Lumen (measured): 2400 lm
Reference value: 12.5
Cord length: 500 mm
Frame material: aluminium
Lens material: polycarbonate
IP rating: IP67
Approvals: ECE R10, R112, R7

SALA is a popular, powerful driving light from Strands Lighting Division. Innovative design with LED marker lights in the middle. Ultra slim design making it easy to fit in almost all car models. Recommended to be fitted with all three screws, but can also be fitted with just one or two screws.

New for the season, a sharp addition to the range of round, powerful auxiliary lights. Attracting attention with its looks, features and performance! Futuristic design, equipped with two park colour options and a light output that is undeniably a wedge in the ultimate battle. Top polished optics: optimum light distribution. Warning light built into the top of the lens.

Dimensions: ø 229.00 x 85.00mm
Weight: 2.82 kg (net 2.82 kg)
Voltage: 12-48V
Lumens: 9000 lm
Lumens (measured): 8170 lm
Reference value: 17.5
Colour: white
Shape: round
Colour temperature: 5500 K
Range, 1 lux: 266 m
Double range, 1 lux: 747 m
Plug type: 6-pin DT
Lead length: 2.20 m
Approvals: R148, R149, R10, R65 cl.1
Model name: Fury 9" White
Details: 16 LEDs, two riser colour options: amber and bright, integrated warning light neatly hidden in the upper part of the lens. Frameless lens withstands shocks and impacts and won't collect dirt or snow. The mounting foot is designed to ensure smooth installation of adjacent lamps. Mode button on the rear to switch between off-road mode and R149 E approved mode. Power consumption 11,86A @ 13,7V DC.

OPTIBEAM NIN9, as the name says, is THE NINE, the best in its class, developed using the latest LED technology and taking into account all the wishes of professional users and installers. The optics are designed to create an unprecedented wide pattern that illuminates the edges of the road, without forgetting that a good auxiliary light must also reach a long distance. Measured per lamp, 1lux @ 580m guarantees that with two, three or four lamps, the beam length and brightness will leave no one cold. The lamp is made frameless according to the latest design trends, preventing ice, snow or dirt from sticking to the glass. The lamp is equipped with the extremely popular two-colour parking function, from which you can choose between a white or orange option. The design, dark optics and eye-catching X-Park create a whole that enhances the look of the vehicle. For ease of installation, the lamp has two alternative mounting brackets, a pedestal mounting bracket and a U-bracket, from which you can choose the more suitable option.

Dimensions: ø 220.00 x 83.00mm
Weight: 2.60 kg (net 2.60 kg)
Voltage: 9-36V
Lumens: 14000 lm
Lumens (measured): 11400 lm
Reference value: 30
Shape: circular
Colour temperature: 5500 K
Plug type: 4-pin DT
Cord length: 850 mm
IP rating: IP68
Approvals: R148/149, R10
Model name: NIN9
Details: 8x LED, Double up. Amber/white park light (both with their own cord). Power consumption: 11.16A@13.7V, 1 lux @ 580 m, R112: 1 lux at 245 m
Warranty (months): 36

Translation results

Are you ready for something completely new? The Firefly One driving light has a unique oval design that will attract attention. The glow of the weightless amber or white marker light creates a unique look, and Firefly One has the added functionality of an integrated warning light.

An exciting marriage of function and design with a new oval headlamp look. The Firefly One driving light has an eye-catching design that will make an exciting addition to any vehicle. The optimised beam has the perfect balance of width and range to give you the best possible driving experience.

Firefly One is a gauge light with a white and amber beam that gives the impression of weightless brilliance in the air, offering a striking and eye-catching look to any vehicle. It is ECE R148/R149 approved and the warning light function is ECE R65 XA2 Class 1 and Class 2. The ingenious design will make it invisible when not in use.

The 2.5 m cable will make installation easy and the Firefly One driving light will enhance the style of any truck, car or tractor, catching the attention of anyone in the vicinity. The optimised beam size is 1 lux at 502 metres and produces an incredible brightness of 10,500 actual lm and a colour temperature of 5700 K. It is made from durable materials and is IP67 rated, guaranteeing long-lasting high performance.

Firefly One's oval design guarantees you a unique look and will integrate seamlessly into your vehicle. The combination of advanced engineering and attention to detail creates a harmonious union of functionality and style. High-quality aluminium and polycarbonate make Firefly One durable and long-lasting, and a 3-year function warranty guarantees long-lasting performance.

Consumption Specifications Function (W)
Warning light: 21W night/36W day White gauge light: 1W Amber light: 1.5W
Voltage (V DC) 10-48V DC
Consumption (W) 146
Articles 2
Functions High beam, amber marker light, white marker light, warning light
Theoretical lumen 15400
Actual lumen 10500
1 LUX @ m 502
Colour temperature (kelvin) 5700
Beam pattern
Optimised beam
Position light
White and amber
Connection Cable
Cable length (mm) 2500
Body colour Black
Colour lens Clear
Colour LEDs White and amber
Material bracket Stainless steel
Material housing/chassis
Aluminium Material lens
Polycarbonate
Length (mm) 245
Depth (mm) 79,5
Height (mm) 154,5
Height including bracket (mm) 172
IP class IP67
Operating temperature -40 - +65°C
E-approved Yes
Complies with Regulation ECE R65 2. Class (XA2), R148(R7), R149(R112)
Reference number 45
EMC ECE R10

Dimensions: ø 218.00 x 87.50 mm
Weight: 4.00 kg (net 4.00 kg)
Voltage: 9-36V
Lumens (measured): 11320 lm
Reference value: 20
Shape: round
Colour temperature: 5000 K
Range, 1 lux: 816 m
Plug type: 2-pin DTP
Cord length: 2.20 m
IP rating: IP68, IP69K
Approvals: R148, R149, R10
Model name: Elite 9
Details: 16xled, Two-color standing beam, dark optics, power consumption 12.33A @ 13.7V
Warranty (months): 36

Are you ready to improve your driving experience with the most exciting driving light on the market? Meet the all-new Optibeam Elite MEGA - the old legendary shape with all-new performance! Designed for drivers who demand excellence and expect more, this advanced lighting solution offers unrivalled range, a wide and sophisticated beam pattern and a high-end, sophisticated design - all in one.

Dimensions: 248.00 x 139.00 (155.00) x 80.50 mm
Weight: 2.00 kg (net 2.00 kg)
Voltage: 9-36V
Lumens (measured): 7780 lm
Reference value: 20
Colour temperature: 5000 K
Range, 1 lux: 329 m
Dual range, 1 lux: 559 m
Plug type: 2-pin DTP
Cord length: 2.20 m
Approvals: R148, R149, R10
Model name: Elite Mega
Information: 12 x LED, power consumption: 8.69A @ 13.7V
Warranty (months): 36

Voltage (V DC) 9-32V DC
Consumption (W) 144.6
Consumption-specific function (W)
White lumen: 5.5 Amber lumen: 5
Theoretical lumen 20400
Actual lumen 11515
1 LUX @ m 387

Description
Not only a stylish addition to any vehicle, but also a light with real power. Dragon Drive offers an extended beam with 9300 lumens, 6500 kelvins and a 586 m range at 1 lux. Installation of the light is easy thanks to the 150 mm cable with DT-4 connector. Constructed from high quality aluminium and polycarbonate, this light is IP67 rated for durability and longevity. The product is covered by a 3 year function guarantee from Strands Lighting Divisions, the market leader.

Functionality and innovation
Strands Lighting Division is passionate about improving every driver's daily life with innovative and quality products. The FOR9T series combines functionality, technology and striking design. The new position light design provides a unique look with hypnotic lines that make the eye move forward and into the future. The wide range of FOR9T products offers a complete and stylish look for any vehicle to make the night your adventure.

FOR9T Dragon Drive benefits

• Customisable position light: White and amber, allowing you to choose the style that suits you best.
• Innovative design: Black body with FOR9T honeycomb pattern in the reflector for high visibility and a unique look.
• Durable construction: Lightweight aluminium body and high quality materials.
• Extended beam with long range and high visibility ensures you can explore the night without obstruction.

Technical data

• Luminous flux: 9300 lm
• Colour temperature: 6500 K
• Range: 586 m at 1 lux
• Material: Aluminium and polycarbonate
• IP class: IP67
• Cable length: 150 mm with DT-4 connector
• Warranty: 3 years

Dragon Drive is your ideal companion on dark roads, offering outstanding performance and a unique design that will enhance any vehicle. The night is yours - explore it with the FOR9T Dragon Drive!

FOR9T DRAGON DRIVE 9″ Driver Light

• PCS

• Voltage: 10-48V DC

• Consumption: 142 W

• Specific Function Consumption:

  • White position light: 3.5 W
  • Amber position light: 3.6 W

• Functions:

  • High beam
  • White position light
  • Amber position light
  • Logo light

• Theoretical luminous flux: 14000 lm

• Actual luminous flux: 9300 lm

• 1 LUX @ m: 586 m

• Colour temperature: 6500 K

• Light pattern: Extended beam

• Position light colour: White and amber

Connections and materials

• Compound: DT-4

• Cable length: 150 mm

• Housing colour: Black

• Lens colour: Transparent/dark

• LED colours: White and amber

• Fixing material: Stainless steel

• Housing material: Aluminium

• Lens material: Polycarbonate

Dimensions and protection

• Depth: 90 mm
• Height (including mount): 226 mm
• Diameter: 220 mm
• IP class: IP67
• Operating temperature: -40 °C to +65 °C

Other features

• E-approval: No
• EMC: ECE R10

Dragon Drive is a reliable, durable and powerful lighting solution that provides great visibility and personalised styling for your vehicle.

Voltage (V DC) 10-32V DC
Consumption (W) E-mode: 19W Xperience mode: 164W
Consumption-specific function (W)
White gauge light: 6.9w Amber gauge light: 7.1w
Functions High beam, Amber and white spotlight, Separate Hello function for spotlight, Logo light
Theoretical lumen 18,000
Actual lumen E mode: 1,430 Xperience mode: 1,350
1 LUX @ m
E mode: 319 Xperience mode: 881
Colour temperature (kelvin) 5700 thou
Beam pattern Long distance beam
Position light White and amber
Connection DT-4
Cable length (mm) 150
Colour body Black
Colour lens Main lens: transparent, External lens cap: Black and yellow flood versions Colour LEDs White and amber

Length (mm) 220.4
Depth (mm) 99.3
Height (mm) 212.6
Height including bracket (mm) 233,1
IP class 68/69 th
Operating temperature -30°C - +65°C
E-approved
Yes
In compliance with regulation
ECE R148(R7), R149(R112)
Reference number
20
EMC
ECE R10, CISPR25 3. Class
PERSONAL

Dimensions: 177.80 x 167.80 (185.00) x 89.60 mm
Weight: 1.82 kg (net 1.82 kg)
Voltage: 12-48V
Lumens: 6700 lm
Lumens (measured): 6130 lm
Reference value: 20
Shape: round
Colour temperature: 5700 K
Range, 1 lux: 290 m
Double range, 1 lux: 454 m
Plug type: 4-pin DT
Cord length: 2.20 m
Frame material: aluminium
Lens material: polycarbonate
IP rating: IP67
Approvals: ECE R148, R149, R10, R65
Model name: Fury 7"
Details: 10 LEDs, two riser colour options: amber and bright, integrated warning light. Frameless lens withstands shocks and impacts and does not collect dirt or snow. The mounting leg is designed for smooth installation of adjacent lamps. Power consumption 7,52A @ 13,7V DC.

Lamp type LED
PCS LEDs 34
Voltage (V DC) 9-32V DC
Theoretical power (w) 12V 170
Theoretical power (w) 24V 170
Consumption (w) 12V 145.3
Consumption (w) 24V 144.6
Theoretical lumen 20400
Actual Lumen 13377
1 LUX @ m 465
Kelvin 6000
IP class 67/69
Color body Black
Color lens Clear
Color LEDs White and amber
Position light Yes, amber and white
Connection DT-4
Cable length (mm) 500
Material bracket Stainless steel
Material body/chassis Aluminum
Material lens Polycarbonate
Length (mm) 228.6
Depth (mm) 86.7
Height (mm) 228.6
Height including bracket (mm) 249.3
Diameter (mm) 228.6
Operating temperature -30°C - +65°C
ADR approved No
E-approved Yes
According to regulation ECE R112, R7
Reference number 30
EMC ECE R10

Maximum light output. Siberia gives you a whole new level of efficiency on all roads and in all conditions. Perfect for all kinds of driving. The power of LEDs expands the field of vision in the perfect balance of length and width - in the proven, well-known combination of Siberia LED bars.

Amber or white? Which color describes your style and personality? A double-decker light allows you to choose. Regardless of the choice, the position light gives an excellent light effect, perfectly placed in a circle with a break line in the middle.

DURABLE MATERIAL
The lens is made of transparent PC (polycarbonate), an extremely durable material with good light transmission that protects the diodes from scratches and the weather. The durable black aluminum body withstands the salt and other stresses of the harsh Nordic climate.

Dimensions: 245.00 x 140.00 x 91.00 mm
Weight: 3.00 kg (net 3.00 kg)
Voltage: 10-30V
Lumens: 6500 lm
Lumens (measured): 4770 lm
Reference value: 20
Shape: Rectangle
Colour temperature: 6000K
Plug type: 3-pin open cable
Cord length: 300 mm
Model name: QUADRATOR LED
Details: 8x8W CREE LED, 6500lm, 6000K. 3 years warranty, power consumption 3.87A @ 13.7V
Warranty (months): 36

SIBERIA X 7" Driving Light - Powerful and Durable Lighting Solution

Outstanding Light Output and Lighting Range
The SIBERIA X 7" emits 1640-7430 actual lumens, making it an extremely powerful lighting solution even on the darkest nights. The optimised beam provides an illumination range of 308-620 metres, effectively illuminating both the road ahead and the sides. This makes this headlamp a reliable companion in difficult driving conditions.

Durable Construction and Long Life
SIBERIA X is made of durable materials and coated with a new generation powder coating for long life in all conditions. Thanks to its IP68/IP69K protection class, it is fully dustproof and waterproof, ensuring maximum durability even in extreme weather conditions.

Simple Installation and Connectivity
The lamp is equipped with a DT-4 connector and a 150 mm cable, which ensures quick and easy installation without the complexity of unnecessary cabling.

ECE Certification and Regulatory Compliance
SIBERIA X 7" is E-approved to ECE R149 (R112), R148 (R7) and EMC certified to ECE R10, CISPR25 Class 3, which means it meets all the necessary safety and performance requirements.

Unique Design and Innovative Features
As part of the Xperience series, this driving light stands out for its unique visual appearance and clever design. Its square body offers versatile mounting options, while the rounded lens edges provide wide side illumination. The X-shaped bi-position light complements the shape of the lens and offers two choices of white or amber position illumination.

New Hello Function
The exclusive Hello function of the Xperience Series allows you to signal other drivers - simply double-flick the high beam and the Hello signal of the position lights is activated. The light shines through the back of the housing, creating a noticeable effect from any angle.

SIBERIA X 7" - The perfect solution for professionals and adventurers who want powerful, reliable and stylish lighting!

• Technical Specifications - SIBERIA X 7" Driving Light

  • Unit.
  • Voltage (V DC): 10-32
  • Consumption (W):
    • E-mode: 22W
    • Xperience mode: 96W
  • Consumption (W) for specific functions:
    • White position light: 6W
    • Amber position light: 6.8W
  • Features:
    • Low beam
    • Amber and white position light
    • Separate "Hello" function for position light
    • Illuminated logo
  • Theoretical lumens: 10 000 lm
  • Actual lumens:
    • E-mode: 1640 lm
    • Xperience mode: 7430 lm
  • 1 LUX distance (m):
    • E-mode: 308 m
    • Xperience mode: 620 m
  • Colour temperature (Kelvin): 5700K
  • Beam Type: Extended Beam
  • Beam angle (°) (width): 10,7°
  • Position beam: White and amber
  • Connection: DT-4PIN
  • Cable length (mm): 150 mm
  • Housing colour: Black
  • Lens colour:
    • Main lens: transparent
    • Outer lens coating versions: black and yellow flood light
  • LED colour: White/Amber
  • Bracket material: Stainless steel
  • Housing/chassis material: Aluminium
  • Lens material: Polycarbonate
  • Dimensions (mm):
    • Length: 173.4 mm
    • Depth: 83.3 mm
    • Height: 169.9 mm
    • Height with bracket: 191.6 mm
  • IP protection class: IP68 / IP69K
  • Operating temperature: -30°C to +65°C
  • E-approval: Yes
  • Regulatory compliance: R148 (R7), R149 (R112)
  • Reference number: 20

Dimensions: 178.00 x 170.00 x 72.00 mm
Voltage: 10-38V
Lumens: 8250 lm
Lumens (measured): 5850 lm
Reference value: 25
Colour: black
Shape: round
Colour temperature (measured): 5700 K
Range, 1 lux: 317 m
Double range, 1 lux: 628 m
Plug type: 4-pin DT
Cord length: 500 mm
Frame material: aluminium
Lens material: polycarbonate
IP rating: IP68, IP69K
Approvals: ECE R10, CISPR25 3. Class R&E R10
