Description
OPTIBEAM NIN9, as the name says, is THE NINE, the best in its class, developed using the latest LED technology and taking into account all the wishes of professional users and installers. The optics are designed to create an unprecedented wide pattern that illuminates the edges of the road, without forgetting that a good auxiliary light must also reach a long distance. Measured per lamp, 1lux @ 580m guarantees that with two, three or four lamps, the beam length and brightness will leave no one cold. The lamp is made frameless according to the latest design trends, preventing ice, snow or dirt from sticking to the glass. The lamp is equipped with the extremely popular two-colour parking function, from which you can choose between a white or orange option. The design, dark optics and eye-catching X-Park create a whole that enhances the look of the vehicle. For ease of installation, the lamp has two alternative mounting brackets, a pedestal mounting bracket and a U-bracket, from which you can choose the more suitable option.
Dimensions: ø 220.00 x 83.00mm
Weight: 2.60 kg (net 2.60 kg)
Voltage: 9-36V
Lumens: 14000 lm
Lumens (measured): 11400 lm
Reference value: 30
Shape: circular
Colour temperature: 5500 K
Plug type: 4-pin DT
Cord length: 850 mm
IP rating: IP68
Approvals: R148/149, R10
Model name: NIN9
Details: 8x LED, Double up. Amber/white park light (both with their own cord). Power consumption: 11.16A@13.7V, 1 lux @ 580 m, R112: 1 lux at 245 m
Warranty (months): 36
