50kW Hybrid Inverter Three Phase

Name: 50kW Hybrid Inverter Three Phase
Brand: Ledakcijas
SKU: 11861
Price: 6449.0 EUR
Availability: InStock

SKU: 11861

€6.449,00

Data sheet

Share this product

Specifica

General Information

Electrical Data

Current

PV Input Current: 36+36+36+36A;
Max. PV ISC (A): 55+55+55+55
No.of MPP Trackers: 4

Wattage

Max. Input Power: 65000W;
Rated Output Power: 50000W;
Max. Output Power: 55000W;

Voltage

Start Voltage: 180V;
Rated Input Voltage: 600;
Full-load DC Voltage Range: 450-850V;
MPPT Voltage Range: 150-850V;

Frequency

50Hz / 60Hz

Power Factor

0.8 lagging to 0.8 leading

Capabilities

IP Rating

IP65

Working conditions

-40~60°C, >45°C derating

Dimensions

Size

527x894x294 mm

Product Data

Order code

11861

Item Weight

100 kg

Item Volume

0.3821

Items per box

Product code

SUN-50K-SG01HP3-EU-BM4

Additional

Release Date

18.12.2023

Brand

V-TAC

Warranty

10 years

tions

Download 11861-Manual-instructions.pdf

Download 11861-Technical-Specifications.pdf

Download 11861-LVD-License.pdf

Download 11861-Ning_SUN-50K-40K-SG01HP3-EU-BM4_-_SUN_35K_29.9K-SG01HP3-EU-BM3_UNBED_EN_50549-1_2019_U23-0129_1_EN.pdf

Download 11861-CEI-0-16.pdf

Download 11861-CEI-0-21-Ning_Sun29.9-50k_BosG_CEI_021_2022-03__ita_eng_23-068-00.pdf

Download Deye-SUN-Series-Hybrid-Inverter-10-Year-Limited-Warranty-for-Installation-in-Europe.pdf

Download 11861-ENB2209280102E00201C-EMC-License.pdf
