20kW Hybrid Solar Inverter Three Phase Low Voltage
Roll over image to zoom in Click on image to zoom
20kW Hybrid Solar Inverter Three Phase Low Voltage
20kW Hybrid Solar Inverter Three Phase Low Voltage
20kW Hybrid Solar Inverter Three Phase Low Voltage
20kW Hybrid Solar Inverter Three Phase Low Voltage

20kW Hybrid Solar Inverter Three Phase Low Voltage

SKU: 12185
€2.976,60
Data sheet

Description

Product description: 15kW Hybrid Solar Inverter Three Phase Low Voltage

This 15kW hybrid solar inverter is a high performance and versatile solution for solar power systems, providing efficient and reliable low voltage operation. Suitable for a variety of environments and conditions, the inverter offers IP65 protection and is ideal for domestic and commercial applications.

General information

  • Brand: V-TAC
  • Product code: SUN-20K-SG05LP3-EU-SM2
  • Order Code: 12185
  • Warranty: 5 years/10 years (see warranty terms)
  • Release date: 29.08.2024

Electrical data

  • Current:

    • Max. PV input operating current: 36+20 A
    • Max. Short-circuit current: 54+30 A
    • Rated AC input/output current: 30.4/29 A
    • Max. 70 A

  • Power:

    • Max. Input Power: 30000 W
    • Rated active AC input/output power: 20000 W
    • Max. 22000 VA

  • Voltage:

    • Rated PV input voltage: 550 V
    • MPPT range: 160-650 V
    • Rated input/output voltage/range: 220/380 V, 230/400 V (0.85Un-1.1Un)
    • Start voltage: 160 V

  • Frequency:

    • Rated mains input/output frequency/range: 50/45-55 Hz, 60/55-65 Hz

  • Power factor:

    • 0.8 driver to 0.8 inhibitor

Capacities and working conditions

  • IP class: IP65
  • Operating temperature: -40 to +60℃ (above 45℃ reduced performance)

Dimensions and weight

  • Dimensions: 456 × 750 × 268.5 mm (excluding connectors and fasteners)
  • Weight: 50.6 kg
  • Units per pack: 1

Specification

Download SKU-12185.pdf
