Wi-Fi signal boosters

Tip: Access Point
Model: Ruijie Reyee RG-RAP6262(G)
Wi-Fi standard: Wi-Fi 6 (802.11ax)
Ports: 2 × 1 Gbps RJ45
Wi-Fi speed: up to 574 Mb/s @ 2.4 GHz; up to 1201 Mb/s @ 5 GHz
Recommended number of connected devices: 256 (max. 512)
MIMO technology: 2×2 @ 2.4 GHz; 2×2 @ 5 GHz
Power consumption: ≤ 18 W
Power input: 802.3at (PoE+)
Operating temperature: −30 °C to +65 °C
Protection class: IP68
Warranty: 3 years

General Information

Wireless protocol: Wi-Fi 6, up to 1,775 Mb/s
MIMO: 2×2 @ 2.4 GHz; 2×2 @ 5 GHz
Protection class: IP68
Dimensions: 200 × 220 × 166 mm (without mounting bracket)
Power: 802.3at PoE, 12 V / 2 A DC
Network ports: 2 × 10/100/1000 Base-T
Maximum number of clients: 256
Operating temperature: −30 °C to +65 °C
Weight: 1.2 kg (without mounting bracket)
Power consumption: ≤ 18 W

Wireless standards
IEEE 802.11n, IEEE 802.11g, IEEE 802.11b

Frequency
2.4-2.5 GHz

WiFi speed up to 300Mbps Receive sensitivity
- 11g54 M: -79dBm
- HT20MCS7: -76dBm
- HT40MCS7: -72dBm

Transmit power <20dBm Wireless security
WPA-PSK/WPA2-PSK

Hardware dimensions
101 x 74.8 x 75.8 mm

Button reset/WPS button antenna type
3 external antennas

300 Mbps range extender

Flexible deployment

Dual-band Wi-Fi coverage for better connectivity.

2.4 GHz 300 Mbps and 5 GHz 867 Mbps dual band.

The smart signal light helps you easily find the best place to install the RE305. Built-in access point mode -
The RE305 is more than a wireless range extender. Simply plug an Ethernet cable into its Ethernet port to easily turn your wired Internet connection into a dual-band wireless access point.

RE305 works with all Wi-Fi routers. You can use TP-Link's free Tether app to set up your range extender from any Android or iOS device in minutes. This feature-rich phone app lets you enjoy not only hassle-free installation, but also access to advanced network management.

Simple installation in the Tether application.

Description

6-port Fast Ethernet switch with PoE+ power supply

The Ruijie Reyee RG-ES106F-P is an unmanaged 6-port switch designed for connecting IP cameras, wireless access points, IP phones, and other PoE devices. It is equipped with 4 PoE+ ports and 2 uplink ports, ensuring simple and reliable network setup.

PoE+ power delivery of up to 30 W per port

The four PoE ports support the IEEE 802.3af/at standards and are capable of delivering up to 30 W of power per port. The total PoE power budget is 54 W, which allows multiple network devices to be powered simultaneously.

Extended Transmission Mode

In Extend mode, the data transfer rate of PoE ports is reduced to 10 Mb/s, allowing for a data transfer distance of up to 200 m, while under laboratory conditions, using high-quality Cat5e or higher-category cable, the distance can reach up to 250 m. This mode is particularly well-suited for video surveillance systems.

Port Isolation Feature

In Isolation mode, PoE ports do not communicate with each other but maintain a connection with the uplink ports. This improves network security and reduces the likelihood of unwanted data traffic.

Durable metal housing

The switch is housed in a metal enclosure with a fanless design, which ensures quiet operation, efficient heat dissipation, and a long service life.

Plug & Play Functionality

The device requires no configuration—simply connect the power supply and network devices, and the switch will start working immediately. It is suitable for homes, offices, stores, and video surveillance systems.

Specifications

Model: RG-ES106F-P

Type: Unmanaged PoE Switch

Number of ports: 6 × RJ45 10/100 Mb/s

PoE ports: 4

Upload ports: 2

PoE standard: IEEE 802.3af/at

Maximum PoE power per port: 30 W

Total PoE power budget: 54 W

Switching capacity: 1.2 Gb/s

MAC Address Table: 2,000 entries

Surge protection: 4 kV

Operating modes: Default, Extend, Isolation

Maximum transmission distance in Extend mode: up to 200 m

Power supply voltage: 100–240 V AC, 50/60 Hz

Maximum power consumption: up to 60 W

Operating temperature: 0 to 45 °C

Housing material: Metal

Cooling: Fanless

Dimensions: 166 × 132.6 × 43 mm
