Products

Specifications

General Information
LED chip: SMD CREE
Lifespan: 30,000 hours

Technical Specifications
Power: 200 W
Voltage: AC 220–240 V
Frequency: 50 Hz

Technical Specifications
Beam angle: 115°
Luminous efficacy: 135 lm/W
Light color: White
Color temperature: 6500 K
Luminous flux: 27,000 lm
Color rendering index (CRI): >70

Housing components
Body color: Black
Material: Aluminum

Opportunities for Action
Protection class: IP65
Time to reach 100% brightness: 0.001 s (instant-on)
Color stability: <6
Operating temperature range: -20 °C to +45 °C

Dimensions
. Dimensions: 406 × 47 × 333 mm

Product details
Order code: 232216
Product code: VT-44201
Number of units per package: 1
Product weight: 2.95 kg
Product volume: 0.00981 m³
Number of units per box: 2
EAN code: 3800170252356

Certifications and Standards
Certification: CE, EMC, RoHS
Energy Efficiency Class: D

Additional information
Release date: October 7, 2025
Brand: V-TAC
Warranty: 6 years

LEDWISE WORK LED light strip for indoor and outdoor lighting

The powerful LEDWISE LED light strip delivers 1500 lm of light per metre, offering high lighting efficiency for both professional and home use. With a high colour rendering index (CRI 82+) and a colour temperature of 4000 K, the light is natural and accurately reproduces the colours of the environment, making this tape particularly suitable for precision work and areas where it is important to see unevenness.

The tape is useful for illuminating renovation and construction sites, as well as halls, warehouses and other hard-to-illuminate areas. Thanks to its IP65 protection class, it is also suitable for outdoor use in courtyards, terraces, on fences, in fields or on building facades.

LEDWISE WORK tape operates at 230 V mains voltage and contains 180 LEDs per metre. The dark colour helps it to blend visually into a dark background when the lights are not on, giving an inconspicuous appearance.

Specifications

Length: 20,00 m
Weight: 4,00 kg (net)
Colour temperature: 4000 K
Voltage: 230 V (power plug not included)
Details: LEDWISE WORK 50 m working LED light tape reel (this is the 20 m segment). Mains plug available separately (product codes: 1700-AT114 or 1700-AT115).
Warranty: 12 months

Features and Details

Bright and even lighting: The oxidation-resistant surface maintains brightness while softening the light, ensuring pleasant and eye-friendly illumination. The LED aluminum profile with a milky white diffuser gives the interior an elegant and modern look.

Enhanced protection: Anodized aluminum ensures effective heat dissipation, extending the LED's service life. The diffuser cover protects the LED strip from dust, moisture, and dirt, preventing yellowing and warping.

Easy installation: First, secure the mounting clips, install the profile, insert the LED strip, press on the diffuser, and attach the end caps. The complete kit allows for quick and easy installation, even without any experience.

Wide range of applications: Suitable for bookshelves, under cabinets, wardrobes, display cases, and room corners. Also ideal for decorative lighting during holidays such as Easter and Christmas.

Various options: Several profile types are available— U-shaped for concealed lighting, an extended U-shape for soft, glare-free lighting, V-shaped for accent lighting, and double-sided recessed profiles for a seamless design

Power supply for LED strips and LED displays
Overvoltage protection: 115%–135%, automatic shutdown
Short-circuit protection, stable output voltage
Built-in EMI filter
High efficiency, low operating temperature
100% full-load tested

Power Supply for LED Strips and LED Displays
Overvoltage protection: 115%–135%, automatic shutdown
Short-circuit protection, stable output voltage
Built-in EMI filter
High efficiency, low operating temperature
100% full-load tested

Apraksts

200 W barošanas bloks magnētiskajai sliežu sistēmai

FOSE TR20-PS-200W ir 200 W barošanas bloks, kas paredzēts 48 V magnētisko sliežu apgaismojuma sistēmu barošanai. Tas ir savietojams ar 20 mm magnētiskajām sliedēm un nodrošina stabilu 48 V DC izejas spriegumu.

48 V DC izeja

Barošanas bloks pārveido 180–265 V AC elektrotīkla spriegumu par 48 V DC, nodrošinot maksimālo 4 A izejas strāvu un līdz 200 W izejas jaudu.

Augsta darbības efektivitāte

Barošanas bloka efektivitāte ir 90%, nodrošinot efektīvu elektroenerģijas pārveidošanu un stabilu magnētiskās sliežu sistēmas darbību.

Aizsardzība pret īssavienojumu

Iebūvētā aizsardzība pret īssavienojumu palīdz aizsargāt barošanas bloku un pievienotos magnētiskās sliedes gaismekļus elektrisku bojājumu gadījumā.

Aizsardzība pret pārslodzi

Integrētā pārslodzes aizsardzība palielina sistēmas ekspluatācijas drošību un palīdz aizsargāt barošanas bloku, ja pievienotā slodze pārsniedz pieļaujamo līmeni.

Izturīgs metāla korpuss

Barošanas bloks ievietots izturīgā metāla korpusā. Šaurā konstrukcija ir piemērota izmantošanai kopā ar modernām 20 mm magnētisko sliežu apgaismojuma sistēmām.

Paredzēts lietošanai iekštelpās

FOSE TR20-PS-200W nav paredzēts lietošanai ārpus telpām. Tas piemērots dzīvojamo, komerciālo, biroju, viesnīcu, veikalu un citu iekštelpu 48 V magnētisko sliežu apgaismojuma sistēmām.

Specifikācija

Ražotājs: FOSE
Modelis: TR20-PS-200W
Produkta veids: magnētiskās sliedes barošanas bloks
ETIM klase: DC barošanas avots
Saderīgā sistēma: 20 mm magnētiskā sliežu sistēma
Ieejas spriegums: 180–265 V AC
Frekvence: 50/60 Hz
Izejas spriegums: 48 V DC
Nominālā jauda: 200 W
Maksimālā izejas strāva: 4 A
Efektivitāte: 90%
Korpusa materiāls: metāls
Elektroaizsardzības klase: I
Aizsardzība pret īssavienojumu: jā
Aizsardzība pret pārslodzi: jā
Piemērots lietošanai ārpus telpām: nē
Izmēri: 300 × 22 × 43 mm
Svars: 0,36 kg
EAN: 6970602185006

• MR200N-20B Length 270 mm, Width 22 mm, Height 45 mm


  Product Specifications

  Product Name	100W Magnetic Lamp Power Supply	200W Magnetic Lamp Power Supply	100W Magnetic Lamp Power Supply	200W Magnetic Lamp Power Supply
  Model No.	MR100N-20B	MR200N-20B	MR100W-20B	MR200W-20B
  Input voltage	AC180V~265V 50/60Hz	AC180V~265V 50/60Hz	AC100V~265V 50/60Hz	AC100V~265V 50/60Hz
  Output voltage	DC48V 2.1A	DC48V 4.2A	DC48V 2.1A	DC48V 4.2A
  Rated power	100W	200W	100W	200W
  Operating temperature (Ta)	40°C	40°C	40°C	40°C
  Maximum temperature (Tc)	85°C	85°C	85°C	85°C
  Product Dimensions (Length x Width x Height)	223 × 22 × 45 mm (W × D × H)	270 × 22 × 45 mm (W × D × H)	223 × 22 × 45 mm (W × D × H)	270 × 22 × 45 mm (W × D × H)
  Weight (including packaging)	0.318 kg	0.362 kg	0.318 kg	0.362 kg
  Package Quantity	50 pcs.	50 pcs.	50 pcs.	50 pcs.
  Gross Weight (G.W.)	16.9 kg	19.1 kg	16.9 kg	19.1 kg




Produkta īpašības

2 × 100 W paneļi

200 W jauda, savienojot paralēli

Universāla XT60 izeja enerģijas stacijai

Komplektā kabeļi, adapteri un īsā lietošanas instrukcija

Quick Charge ātrā uzlāde: 18 W katram panelim

2 × USB-A izejas katram panelim

USB-C Power Delivery izeja: 45 W katram panelim

Viedtālruņa uzlādes laiks: 2 stundas katram panelim

Pārnēsājami un salokāmi

Izmēri atvērtā veidā: 1729 × 423 × 5 mm katram panelim

Neto svars: 4 kg katram panelim

Videi draudzīgi

Ūdensizturība: IPX4

Salokāmo 2 paneļu saules paneļu komplekts SP200W

Šis CANYON saules paneļu komplekts ir kompakts tīras enerģijas avots dažādām situācijām. Komplektā ietilpst divi 100 W paneļi un viss nepieciešamais aprīkojums to savienošanai.

Savienojot divus CANYON saules paneļus paralēli, iespējams iegūt vēl uzticamāku un efektīvāku elektroenerģijas padevi. Izbaudiet tīras, videi draudzīgas un pārnēsājamas enerģijas risinājuma priekšrocības, vienlaikus uzlādējot vairākas ierīces.

Ar kopumā četrām USB-A izejām un divām 45 W USB-C Power Delivery pieslēgvietām iespējams nodrošināt enerģiju dažādām ierīcēm, tostarp klēpjdatoriem, kamerām un viedtālruņiem.

Universālais XT60 savienotājs ļauj pievienot paneļus enerģijas stacijai, padarot tos īpaši noderīgus ārkārtas situācijās vai elektroenerģijas padeves pārtraukuma laikā mājās.

Saules paneļi ir salokāmi, viegli un ērti pārnēsājami, tāpēc tie ir lieliski piemēroti piedzīvojumiem un aktivitātēm brīvā dabā.

Tie ir izstrādāti arī lietošanai nelabvēlīgākos laikapstākļos un nodrošina IPX4 ūdensizturību, tāpēc saglabā funkcionalitāti arī neliela lietus laikā.

Ar šo CANYON saules paneļu komplektu varat izmantot saules enerģiju neatkarīgi no tā, kurp ved jūsu ceļojums.

2 saules paneļi, katrs 100 W

Pārnēsājami un salokāmi

Saderīgi ar enerģijas stacijām

Ideāli piemēroti kempingam, rezerves elektroapgādei mājās un enerģijas nodrošināšanai attālās vietās

[ATTĒLS]

Raksturlielumi

Dizains un funkcijas

Ierīces tips: saules panelis

Ierīces novietojums: ārējs

Ieejas strāvas savienotāja tips: USB

Maksimālā izejas jauda: 200 W

Barošanas adaptera un barošanas funkcijas: Qualcomm Quick Charge 3.0

Power Delivery

Garantija

Preci iespējams atgriezt garantijas ietvaros: jā

Garantijas termiņš: 24 mēneši

Garantijas apstiprināšanas kritērijs: sērijas numurs

Papildu informācija

Modeļa nosaukums: SP-200

Ražotājs: CANYON

Preces kods: CND-SP200W2P

Produkta tips: saules panelis

Cita informācija

Komplektā iekļautā dokumentācija: īsā lietošanas instrukcija

Garantijas karte

Stable 12 V power supply for LED lighting

The V-TAC VT-13201 power supply converts 200–240 V AC to a stable 12 V DC and provides up to 200 W of output power. It is suitable for V-TAC LED strips, LED modules, and other compatible LED lighting devices.

Short-Circuit and Overload Protection

The power supply unit is equipped with protection against short circuits and overloads. A stable output voltage helps ensure reliable operation of the connected LED lighting.

Built-in electromagnetic interference filter

The built-in EMI filter helps reduce electromagnetic interference. High efficiency and low operating temperature contribute to stable and long-lasting operation of the power supply unit.

Plastic housing with IP44 protection

The white plastic housing measures 320 × 41 × 30 mm. The IP44 protection rating ensures protection against the ingress of solid particles and water splashes. The power supply unit has been tested at 100% of its rated load.

Specifications
Brand: V-TAC
Model: VT-13201
Product Code: 24271
EAN Code: 3800170259218
Power: 200 W
Input voltage: 200–240 V AC, 50/60 Hz
Output voltage: 12 V DC
Output current: 16.5 A
Dimmable: No
Housing material: Plastic
Color: White
Dimensions: 320 × 41 × 30 mm
Protection rating: IP44
Customs commodity code: 85044095
Package dimensions: 323 × 44 × 33 mm
Gross weight: 0.46 kg
Quantity per box: 50 pcs.

Stable 24 V Power Supply for LED Lighting

The V-TAC VT-24203 power supply converts 200–240 V AC to 24 V DC and provides 200 W of output power. It is suitable for LED strips and other compatible 24 V LED lighting devices.

Short-Circuit and Overload Protection

Built-in protection against short circuits and overloads helps ensure safe operation and a stable output voltage.

Built-in EMI filter

An electromagnetic interference filter helps reduce electrical interference. High operational efficiency and low operating temperature contribute to reliable and long-lasting power supply operation.

IP44 protection rating

The power supply unit's plastic housing provides IP44 protection. The device has been tested at full rated load.

Specifications
Brand: V-TAC
Model: VT-24203
Product Code: 24252
EAN Code: 3800170259003
Power: 200 W
Input voltage: 200–240 V AC, 50/60 Hz
Output voltage: 24 V DC
Output current: 8.3 A
Dimmable: No
Housing material: Plastic
Color: White
Dimensions: 320 × 41 × 30 mm
Protection rating: IP44
Customs commodity code: 85044095
Package dimensions: 323 × 44 × 33 mm
Package volume: 0.0006 m³
Gross weight: 0.45 kg
Quantity per box: 50 pcs.

Boost your energy supply: use the VEVOR 200W monocrystalline solar panel kit, ideal for homes, trailers, camping or yachts. Whether it's a backup power source at home or to charge your vehicle while travelling, wait no more - your devices will always have power!

Wide compatibility. Compatible with different battery types - AGM, GEL, FLD, LI - it's your ultimate source of emergency power. Whether outdoors or at home, you're always prepared and ready for anything.

Outstanding energy conversion: powered by high efficiency monocrystalline solar cells, our 12V monocrystalline PV module offers a high energy conversion efficiency of over 23%. It is an ideal energy source for a wide range of extreme conditions, capable of operating from -10℃ to 65℃ temperatures (optimally at 25℃).

Durability redefined: Built to last with temperature resistant glass and corrosion resistant aluminium frames, our high efficiency solar panel withstands tough conditions. IP68 waterproof and durable, it delivers reliable energy and stable output, unaffected by adverse weather or wear and tear.

Easy installation: with a generous set of connection accessories, our solar panel ensures easy installation, making renewable energy more accessible than ever. Simple, fast and efficient - it's time to power your devices with clean energy that's instantly available when you want it.

High-quality LED SMD-CREE chip and high-power driver
Front glass hermetically sealed with silicone rubber for excellent water and air tightness
Ability to select and switch the desired color temperature at any timeusing the CCT switch
Complete protection against water, dust, and corrosion — IP65 protection rating
Durable and sturdy aluminum construction with a corrosion-resistant design
Suitable for building facades, sports facilities, industrial areas, commercial displays, advertising posters, parking lots, etc.
