Specifications
Electrical Data
Current
Max. Charging/Discharging Current 240A
Wattage
- Nominal Output Power/UPS Power: 12kW;
- Recommended Energy Configuration: 15kW (Min.);
Voltage
AC Output 3L/N/PE 220/380, 230/400Vac
Frequency
50/60Hz
Capabilities
IP Rating
IP65 (after stacking)
Working conditions
` -20 +55°C
Dimensions
Size
- Inverter: 720 x 255 x H440 mm;
- Battery Module Dimension: 720*255*300(W x D x H, mm);
- Battery Base Dimension: 720*255*68(W x D x H, mm);
- Battery PDU3 Dimension: 720*255*228(W x D x H, mm);
Product Data
Order code
12234
Product code
AI-W5.1-12P3-EU-B
Items per pack
1
Item Weight
325 kg
Item Volume
1.68
Items per box
1
Certificates & Standards
Certification
IEC62619, IEC60730, CE, VDE2510-50, CEI 0-21
Additional
Release Date
16.10.2024
Brand
V-TAC
Warranty
Battery 10 years, Inverter 5 years
